| Conductor Structure |
Conductor Standard |
Conductor Minimum |
Average Thickness |
Min Thickness |
Overall Diameter |
Current AMP |
| pcs/mm |
mm2 |
mm2 |
mm |
mm |
mm |
(A) |
| 31/0.3 |
2.2 |
2.15 |
1.68 |
1.6 |
5.3 |
12 |
| 7/0.85 |
3.97 |
3.9 |
0.8 |
0.72 |
4.2 |
40 |
| 71/0.3 |
5.02 |
4.95 |
1.09 |
1.01 |
5.1 |
49 |
| 85/0.3 |
6.008 |
5.98 |
1.15 |
1.07 |
5.5 |
58 |
| 142/0.3 |
10.04 |
9.98 |
1.3 |
1.22 |
6.8 |
64 |
| 228/0.3 |
16.12 |
15.98 |
0.87 |
0.79 |
7 |
95 |
| 354/0.3 |
25.02 |
24.98 |
1.98 |
1.9 |
10.5 |
110 |
| 496/0.3 |
35.06 |
34.99 |
2.14 |
2.06 |
12 |
225 |
|
|
|
|
