| UL STYLE |
Size |
Conductor Standard |
Conductor Minimum |
Average Thickness |
Min Thickness |
Overall Diameter |
Resistivity |
Standard |
| AWG |
mm2 |
mm2 |
mm |
mm |
mm |
DCR/20℃ |
Feet/Roll |
| UL2468 |
28 |
0.0804 |
0.079 |
0.4 |
0.32 |
1.2*2.4 |
237.25 |
2000 |
| 26 |
0.128 |
0.126 |
0.4 |
0.32 |
1.35*2.7 |
148.94 |
2000 |
| 24 |
0.205 |
0.201 |
0.4 |
0.32 |
1.5*3.0 |
93.25 |
2000 |
| 22 |
0.324 |
0.318 |
0.4 |
0.32 |
1.7*3.4 |
55 |
2000 |
| 20 |
0.519 |
0.509 |
0.4 |
0.32 |
2.0*4.0 |
34.6 |
1000 |
| 18 |
0.823 |
0.807 |
0.4 |
0.32 |
2.1*4.2 |
21.7 |
1000 |
| 16 |
1.31 |
1.28 |
0.4 |
0.32 |
2.4*4.8 |
13.7 |
1000 |
| 14 |
2.07 |
2.01 |
0.4 |
0.32 |
2.8*5.6 |
8.62 |
1000 |
| 12 |
3.29 |
3.2 |
0.4 |
0.32 |
3.5*7.0 |
5.43 |
1000 |
|
|
|
|
